CROSSLOOP, Duckboard anchor
Simple, light and easy to install, it is designed to be installed on platforms, bridges, horizontal surfaces made up of pressed steel gratings, min. mesh 30 mm x 30 mm.
It is designed to be used with a fall arrester system, but can also be used with a work positioning or restraint system.
Consists of a polymer casing with aluminium reinforced plate and steel anchorage axis, and an anchorage wire rope sling having thimbled loop at one end.
Provided with 3 different lengths of wire rope slings (250 mm / 500 mm / 75 mm), as well as with a 8.5 m long cord to facilitate installaton of the fall arrest system.
Weight: 3.75 kg.
Compliance: EN 795:2012 Type B.
Static strength as per EN 795:2012: 12 kN.
HS Code:
To download the instructions for use, see the Attachment tab
